Quadrive Gear Drives

Rexnord is a leading manufacturer of shaft mount gear drives for the heavy-duty industrial market. Our shaft mount gear drives feature rugged designs to meet every operating challenge, and they're site proven in the world's most demanding applications. Rexnord Shaft Mount Gear Drives are application-engineered to minimize stress and wear and extend service life.

Quadrive Installation

Quadrive

Falk 5107J Gear Drives

Falk 5107J Gear Drives

The Quadrive size 5107 has a maximum low speed shaft bore diameter of 1 7/16 inch, and is available in three standard configurations: Shaft Mounted (JR), Flange Mounted (JF), and Screw Conveyor (JSC).

Falk 5115J Gear Drives

Falk 5115J Gear Drives

The Quadrive size 5115 has a maximum low speed shaft bore diameter of 1 15/16 inch, and is available in three standard configurations: Shaft Mounted (JR), Flange Mounted (JF), and Screw Conveyor (JSC).

Falk 5203J Gear Drives

Falk 5203J Gear Drives

The Quadrive size 5203 has a maximum low speed shaft bore diameter of 2 3/16 inch, and is available in three standard configurations: Shaft Mounted (JR), Flange Mounted (JF), and Screw Conveyor (JSC).

Falk 5207J Gear Drives

Falk 5207J Gear Drives

The Quadrive size 5207 has a maximum low speed shaft bore diameter of 2 7/16 inch, and is available in three standard configurations: Shaft Mounted (JR), Flange Mounted (JF), and Screw Conveyor (JSC).

Falk 5215J Gear Drives

Falk 5215J Gear Drives

The Quadrive size 5215 has a maximum low speed shaft bore diameter of 2 15/16 inch, and is available in three standard configurations: Shaft Mounted (JR), Flange Mounted (JF), and Screw Conveyor (JSC).

Falk 5307J Gear Drives

Falk 5307J Gear Drives

The Quadrive size 5307 has a maximum low speed shaft bore diameter of 3 7/16 inch, and is available in three standard configurations: Shaft Mounted (JR), Flange Mounted (JF), and Screw Conveyor (JSC).

Falk 5315J Gear Drives

Falk 5315J Gear Drives

The Quadrive size 5315 has a maximum low speed shaft bore diameter of 3 15/16 inch, and is available in three standard configurations: Shaft Mounted (JR), Flange Mounted (JF), and Screw Conveyor (JSC).

Falk 5407J Gear Drives

Falk 5407J Gear Drives

The Quadrive size 5407 has a maximum low speed shaft bore diameter of 4 7/16 inch, and is available in three standard configurations: Shaft Mounted (JR), Flange Mounted (JF), and Screw Conveyor (JSC).

Falk 5415J Gear Drives

Falk 5415J Gear Drives

The Quadrive size 5415 has a maximum low speed shaft bore diameter of 4 15/16 inch, and is available in three standard configurations: Shaft Mounted (JR), Flange Mounted (JF), and Screw Conveyor (JSC).

Falk 5507J Gear Drives

Falk 5507J Gear Drives

The Quadrive size 5507 has a maximum low speed shaft bore diameter of 5 7/16 inch, and is available in three standard configurations: Shaft Mounted (JR), Flange Mounted (JF), and Screw Conveyor (JSC).

Falk 5608J Gear Drives

Falk 5608J Gear Drives

The Quadrive size 5608 has a maximum low speed shaft bore diameter of 6 1/2 inch, and is available in three standard configurations: Shaft Mounted (JR), Flange Mounted (JF), and Screw Conveyor (JSC).

Documentation

Falk Quadrive Shaft-Mounted Drives – Imperial

371-110E

Catalog | English | 8 MB

Falk Quadrive Shaft Mounted Drives Model A, Sizes 5107-5315

378-200

Manual | English | 3 MB

Falk Quadrive Shaft-Mounted Drives

371100

Brochure | English | 578 KB

Power Transmission Products & Solutions for Refinery and Petrochemical Plants

VM1-011

Brochure | English | 1 MB

Falk Quadrive Motor Mount and Belt Guard Update Guide

GR1-008

Brochure | English | 543 KB

Falk Quadrive Shaft Mounted Drive

371-810

Interchange Guide | English | 2 MB

Product Support

Contact Rexnord to receive product and service information for Quadrive Gear Drives.
